Main parameter of FW-PI10OT1

air volume (m3/h)	effective area (m2)	power supply	power     (W)	water consumption (L/H)	noise  (dB)	dimention (mm)
18000	100-150	220V/380V	1100	10-12	≤73	1100*1100*1950

Distinguishing Feature :

• Energy saving

Low cost of working, evaporative air cooler estimated energy cost of operation less than 1/6 -1/8 that of refrigerated air

• Environment protection

No compressor and no freon

• Obvious effect of lowering temperature

Lower temperature 4-12 centigrade by water evaporation

• Removing dust and ventilation

Evaporative air cooler increase the air oxygen, filter the dust and smell

Advantage:

1. Low running costs. Cool your whole place up to 86% cheaper than other air conditioners

2. Low energy consumption = reduced electricity bills

3. Axial Fan – maximises efficiency

4.Patented motor technology for quiet operation

5.Easy to move

6.Helps eliminate smoke and cooking odours

7.Produce fresh air cooling

8.Helps reduce the spread of infections

9.Environmentally friendly, producing less than 16% of the CO2 greenhouse gases produced by a standard ducted      reverse cycle systems

10. in 1: Air cooler, Fan, Purifier and Humidifier

11.Honeycomb wed pad for optimum performance

12.Simple operation and good appearance

13.Over current and overvoltage protection

14.Mounted with castors for easy mobility

Cooling Principle

The evaporative air cooler cools the air by the evaporation of water. When water evaporatives into the air ,the result is a mixture of air and water molecules. This chemical change requires heat , thus energy or latent heat is taken from the air molecules dropping the actual temperature of the air .

Application:

Used for office, shop, train/bus station, workshop, workers' dormitory, hospital, outdoor/indoor restaurant & coffee bar
